Patellofemoral Pain Exercises: Evidence-Based Loading Guide for Knee Rehabilitation
Interesting research reveals the exact loading of 35 common exercises on your kneecap - better informing us as to which exercises can be used (and when) for knee rehabilitation
Table of Contents
The Research on Patellofemoral Joint Loading
A 2023 study published in the American Journal of Sports Medicine has investigated quantitative measurements of patellofemoral joint loading across 35 common weight-bearing exercises and daily activities.
This interesting research analysed how different exercises load the kneecap (patellofemoral) joint, creating a "loading index" that combines both peak force and cumulative load. This allows us to use scientific evidence to guide exercise progression based on actual joint loading rather than guesswork.
Patellofemoral pain affects approximately 23% of the general population annually and is one of the most common knee conditions among active adolescents and adults. Despite exercise being the cornerstone of treatment, long-term prognosis has the potential to be poor, with 30-50% of patients reporting unfavourable recovery 5-20 years later. This research provides crucial missing information that could significantly improve rehabilitation outcomes.
Exercise Loading Tiers: From Gentle to Advanced
The researchers categorised all 35 exercises into three distinct loading tiers based on their comprehensive loading index:
Key Research Findings
- Most rehabilitation exercises (69%) generate moderate patellofemoral loading
- Few weight-bearing exercises provide truly low-level loading comparable to walking
- Exercises with high knee flexion angles generate higher patellofemoral loading
- Fast, high-intensity exercises often provide lower overall loading than expected
This tiered approach allows for precise exercise prescription based on an individual's current pain level and rehabilitation stage, moving beyond the traditional "no pain, no gain" approach that often worsens patellofemoral symptoms.
Complete Exercise Reference Tables
Use these evidence-based tables to select appropriate exercises for your rehabilitation stage. The loading index combines both peak force and cumulative load on your kneecap (0 = no load, 1 = maximum load).
Tier 1: Low Loading Exercises (Loading Index < 0.333)
Ideal for early-stage rehabilitation, even walking may be painful. These exercises place minimal stress on the patellofemoral joint.
| Exercise | Loading Index | Peak Load (×Body Weight) | Rehabilitation Phase |
|---|---|---|---|
| Walking | 0.042 | 0.6 | Initial rehabilitation, pain management phase |
| Low step-up (10 cm) | 0.105 | 1.7 | Early weightbearing progression |
| Double-leg squat (60°) | 0.220 | 2.5 | Initial strengthening phase |
| Low step-down (10 cm) | 0.205 | 3.1 | Eccentric control training |
| High step-up (20 cm) | 0.225 | 3.6 | Progressive step training |
| Double-leg repetitive lateral jumps (fast) | 0.235 | 4.2 | Early plyometric introduction |
| Single-leg repetitive forward hops (fast) | 0.260 | 4.7 | Early dynamic stability |
| Double-leg repetitive forward jumps (fast) | 0.270 | 4.9 | Early power development |
Tier 2: Moderate Loading Exercises (Loading Index 0.333-0.667)
The largest category, perfect for mid-stage rehabilitation as you build strength and function. These exercises provide therapeutic loading without excessive stress.
| Exercise | Loading Index | Peak Load (×Body Weight) | Rehabilitation Phase |
|---|---|---|---|
| Double-leg repetitive lateral jumps (regular) | 0.300 | 5.1 | Plyometric progression |
| Running | 0.350 | 5.4 | Return to running program |
| Single-leg repetitive lateral hops (fast) | 0.300 | 5.3 | Dynamic single-leg training |
| Run-and-stop | 0.385 | 5.2 | Deceleration training |
| Single-leg drop landing | 0.355 | 4.9 | Landing mechanics |
| Sports movement jump | 0.365 | 5.3 | Sport-specific preparation |
| Single-leg squat (60°) | 0.400 | 4.4 | Single-leg strength building |
| Sumo squat | 0.425 | 4.3 | Hip-dominant strengthening |
| Single-leg repetitive forward hops (regular) | 0.360 | 6.4 | Single-leg power development |
| Double-leg squat (full depth) | 0.415 | 4.5 | Full range strengthening |
| Single-leg repetitive lateral hops (regular) | 0.370 | 6.2 | Lateral power development |
| High step-down (20 cm) | 0.410 | 5.8 | Advanced eccentric control |
| Double-leg drop landing | 0.420 | 5.9 | Bilateral landing mechanics |
| Bulgarian squat | 0.455 | 4.7 | Advanced single-leg training |
| Run-and-cut | 0.463 | 7.1 | Change of direction training |
| Double-leg repetitive forward jumps (regular) | 0.400 | 6.9 | Forward power development |
| Double-leg maximal forward jump | 0.420 | 6.3 | Maximal power training |
| Single-leg maximal forward hop | 0.440 | 6.3 | Single-leg maximal power |
| Single-leg drop vertical hop | 0.435 | 6.6 | Advanced single-leg plyometrics |
| Lunge | 0.515 | 5.1 | Functional strengthening |
| Double-leg drop vertical jump | 0.470 | 6.8 | Advanced bilateral plyometrics |
| Alternating split jumps | 0.465 | 7.0 | Dynamic alternating strength |
| Double-leg countermovement jump | 0.550 | 6.4 | Plyometric progression |
| Single-leg countermovement hop | 0.620 | 6.4 | Advanced single-leg power |
Tier 3: High Loading Exercises (Loading Index > 0.667)
Advanced exercises reserved for final-stage rehabilitation and return to sport. These place a significant load on the patellofemoral joint and should be attempted when lower-tier exercises are pain-free.
| Exercise | Loading Index | Peak Load (×Body Weight) | Rehabilitation Phase |
|---|---|---|---|
| Single-leg squat (full depth) | 0.665 | 6.9 | Advanced strength development |
| 3-second Spanish squat | 0.775 | 4.5 | High-duration loading tolerance |
| Single-leg decline squat | 0.875 | 8.2 | Maximum strength, return to sport |
Your Personalised Strength Rehabilitation Plan
Based on this research, here's a guide to building your knee muscle strength to complement your patellofemoral pain rehabilitation:
Phase 1: Early Rehabilitation (Tier 1 Exercises)
When: You have pain with daily activities, walking, or climbing stairs
Focus: Start with walking and low step-ups. Progress to double-leg squats (60°) and low step-downs as tolerated.
Goal: Reduce pain, restore basic movement patterns, and establish pain-free range
Phase 2: Mid Rehabilitation (Tier 2 Exercises)
When: Tier 1 exercises are pain-free, but higher-impact activities still cause symptoms
Focus: Introduce lunges, single-leg squats (60°), and moderate jumping exercises
Goal: Build strength, improve functional capacity, prepare for return to activities
Phase 3: Advanced Rehabilitation (Tier 3 Exercises)
When: You're pain-free with Tier 2 exercises and preparing for sports return
Focus: Carefully progress to full single-leg squats, Spanish squats, and decline squats
Goal: Maximise strength, build load tolerance for sports demands
Important: Strength alone is not the complete answer to patellofemoral joint pain. Clinically, it's also important to work hard on hip and ankle mobility, as well as rebuilding correct motor patterns to ensure the way you load the knee cap improves, not just how well it tolerates load.
Important Research Limitations
While this study provides invaluable guidance, certain limitations may affect how broadly we can apply these findings:
- Healthy participants: The study analysed healthy adults rather than individuals with patellofemoral pain, so loading patterns might differ in symptomatic populations
- Individual variability: The study provided group averages, but individual anatomy and movement patterns can significantly affect actual joint loading
Applying This Research to Your Knee Pain
This loading data empowers you to make informed decisions about your rehabilitation, but it's not a replacement for professional guidance. Here's how to use this information effectively:
Practical Application Guidelines
- Start lower than you think: Begin with Tier 1 exercises even if they seem too easy
- Use the pain scale: Keep exercise pain at a minimum during activity and ensure it doesn't worsen afterwards
- Progress gradually: Move to the next tier only when current exercises feel too easy and are consistently pain-free
- Listen to your knee: If an exercise causes sharp pain or increased symptoms the next day, return to lower-tier exercises
- Consider the whole kinetic chain: Research increasingly supports addressing hip and ankle mechanics alongside knee strengthening
Remember that patellofemoral pain is multifactorial. While this loading data provides crucial exercise progression guidance, optimal rehabilitation often requires addressing contributing factors such as movement patterns, muscle imbalances, and activity modifications.
